What's the Technical Feasibility of Turbine Oil Purification System, Turbine Oil Purifier?

 Answer:

    Our TY Series Turbine Oil Purification Systems are being successfully used by hundreds of industrial companies which involved in hydropower project, Gulf Fertilizers, Mills and many more turbine users.

   This Turbine Oil Purification Systems are being helped to increase turbine filter life by removing varnish, particles, sludge formed in the oil and stopping its further formation by removing emulsified water and releasing the gas from the oil.   This type Purification System could clean the oil down to NAS 5, removing contamination & particles down to 5 microns,  and emulsified water down to less than 60 ppm, ensuring that there was no valve sticking problem in the governing system.  Customers are unable to achieve these results with the use of a centrifuge.

   Many people may ask:  What's the Technical Feasibility of High Vacuum Turbine Oil Purification System, Turbine Oil Purifier ??

    At the moment, some customer are cleaning the Turbine Oils by centrifuges which remove contamination and free water.

   But Actually, A centrifuge can not remove free water content thoroughly, and it cannot remove emulsified water from turbine oils, which acts as a catalyst to increase oxidation, causes foaming in oils and reduces component life. One of the major problems of continuous water presence in the oil is formation of varnish which is a thin, insoluble film deposit that is usually found on bearings and servo-valves. It is a high molecular weight substance that is insoluble in oil. Varnish insoluble are more than 75 percent soft contaminants that are less than 1 micron in size and are not measured by traditional particle counts. Insoluble compounds have polar affinities and, over time, begin to migrate from the body of the base oil to machine surfaces.

   Initially, the surfaces start to show a golden / dark brown color which then changes to darker gum layers that hardens into lacquer.

   Varnish cannot be removed by a centrifuge. It can block turbine oil filters, servo pencil filters, reduce bearing life, cause servo and directional valves to stick and fail and can even cause turbine shut-down.

   Varnish’s propensity to attract dirt and solid particle contaminants increases component wear. Varnish’s insulation effect causes loss of heat transfer in heat exchangers.

     Therefore,  A high vacuum turbine oil purification system is needed eagerly to solve these problems, for prolonging the oil life and protecting the related systems working properly.

    For more information of high vacuum turbine oil purification system, please goes to our product catagory to find: Turbine Oil Purifier Machine.
